What type of containers can this dumper handle?

This specific unit was designed for Uline Bulk Containers. However, bulk container dumpers are often custom-built or adapted to suit specific container dimensions, such as Eurobins, drums, or bespoke crates. Buyers should confirm compatibility with their existing containers.

Is installation complex for a bulk container dumper?

Installation typically involves bolting the unit to a level, reinforced concrete floor and connecting it to a suitable electrical supply. Professional installation is recommended to ensure correct alignment, safety, and operational integrity.

What maintenance is required for this type of equipment?

Regular maintenance usually includes checking chain tension, lubricating moving parts, inspecting electrical connections, and verifying the functionality of safety interlocks. Adhering to the manufacturer's recommended service schedule is crucial.

Can the discharge height be adjusted?

For this class of equipment, the discharge height is typically fixed as part of its original design. Any adjustments would likely require significant structural modification and re-certification.

What safety standards should I be aware of?

Units should comply with relevant UK and European machinery safety directives, such as the Machinery Directive 2006/42/EC, and standards like BS EN 14120 for guarding. Always check the CE marking and documentation.

Uline Bulk Container Dumper - Lifting & Tipping, photo 1

Uline Bulk Container Dumper - Lifting & Tipping, photo 2

Uline Bulk Container Dumper - Lifting & Tipping, photo 3

Uline Bulk Container Dumper - Lifting & Tipping, photo 4

Uline Bulk Container Dumper - Lifting & Tipping, photo 5

Uline Bulk Container Dumper - Lifting & Tipping, photo 6

Uline Bulk Container Dumper - Lifting & Tipping

Available

Verified seller

Uline Bulk Container Dumper

Name: Uline Bulk Container Dumper
SKU: BTM/2P/500/3700/B/G
Availability: InStock

Price: Contact seller for price

BTM/2P/500/3700/B/G Uline Bulk Container Dumper

This Uline Bulk Container Dumper was designed to lift and tip an Uline Bulk Container (45” x 45” x 33” High) at a discharge height of 3700mm. The Uline Bulk Container Dumper was manufactured from Grade 304 stainless steel, was a welded construction throughout and was designed to be bolted to the floor. The lifting is accomplished via chains driven by a motor gearbox mounted at the top of the one column with a crossover shaft to the other column. The lift carriage was designed to accommodate the Uline Bulk Container but had an adjustable retaining bar with a range of adjustment in 3” increments over a range of 12” – 18”

Safety Guard to BS EN 14120:2015 Safety of Machinery Guards

The Uline Bulk Container Dumper was supplied complete with a safety guard to meet the guidelines of BS EN 14120:2015 Safety of Machinery Guards. The safety guard is constructed from 40 x 40 x 3mm stainless steel box section and 2.0 stainless steel sheet which encloses the Uline Bulk Container Dumper to a height of 2200mm on all sides with a pair of hinged safety guard doors at the loading position. The guard doors are electrically and mechanically interlocked preventing the Uline Bulk Container Dumper from operating when a door is open. Additionally, the guard doors can only be opened when the lift carriage is at the full down position to prevent access whilst a load is raised.

Uline Bulk Container Dumper Electrical Control

This Uline Bulk Container Dumper is fitted with an IP65 Stainless Steel Control Panel which is mounted on the Safety Guard at a convenient position to give good maintenance access under the Provision and Use of Work Equipment Regulation 1998 (PUWER). The control panel incorporates the following controls; Up, Down, Guard Release, Emergency Stop and a Reset Facility.

Upper and Lower end of travel limit switches are positioned to prevent inadvertent adjustment or damage but are easily adjustable by trained personnel for fine adjustment on site. The Uline Bulk Container Dumper operation is latched so that pressing the ‘Up’ push button once will raise the lift to the full tip position. Once the product has been discharged, pressing the ‘Down’ push button once will return the machine to the full down position. The control panel has a volt free pair of contacts which can be used to connect a ‘Call to Run’ signal if required.

Blaenau Gwent County Borough, United Kingdom

5,743 km away

Description

Uline Bulk Container Dumper

Model No.

BTM/2P/500/3700/B/G

Capacity

1100 lbs (500 Kgs)

Overall Height

5778mm

Machine Handing

Left Hand

Maximum Headroom

Mounted Outside

Tipping Chute

Yes, Fitted To Lift Carriage

Container Description

Uline Bulk Container

Base Arrangement

Bolted To The Floor

Control Circuit

24Vac

Electrical Rating

IP65

Limit Switches

Telemecanique

Motor Detail

1.5kW, 460V, 3 PHASE, 60 CYCLE c/w BRAKE

Gearbox Detail

SEW Eurodrive

Tensile Strength

6000 Kgs, 3000 Kgs

Lift Speed

6.4 Meters/Minute

Tension Chain

¾” Simplex

Tip Height

12ft 1 ½” (3700mm)

Tip Angle

130 Degrees

Lift Chain

1" Simplex

Stock Number

BTM/2P/500/3700/B/G

Machinery Masters View

Typical context for this category of equipment. Always confirm specifics with the seller.

Transferring bulk materials from large containers into processing lines or smaller receptacles.
Emptying ingredients in food processing, such as grains, powders, or prepared foods.
Handling waste or recycling materials in industrial settings.
Loading components or raw materials into hoppers or mixers in manufacturing.
Discharging contents of bulk bins in pharmaceutical or chemical industries.

Typical capacity: Units of this class typically handle loads ranging from 250kg to 1500kg, depending on design and intended use.
Discharge height: Commonly found discharge heights for this type of dumper range from 1500mm to over 4000mm.
Material of construction: For food and pharmaceutical applications, Grade 304 or 316 stainless steel is standard; mild steel with a painted finish is common for general industrial use.
Power supply: Typically requires a 3-phase electrical supply, commonly 400V, 50Hz, with varying amperage based on motor size.
Footprint: The base footprint can vary significantly, but units are generally designed to be bolted to the floor for stability.
Safety features: Modern units often include interlocked guarding, emergency stops, and carriage position sensors to comply with safety standards like BS EN 14120.

This specific unit was designed for Uline Bulk Containers. However, bulk container dumpers are often custom-built or adapted to suit specific container dimensions, such as Eurobins, drums, or bespoke crates. Buyers should confirm compatibility with their existing containers.

Lifting and tipping equipment for food handling is valued for durability and reliability in demanding environments. Buyers typically prioritize robust construction, stainless steel components where applicable, and compliance with food safety standards. When purchasing used models, inspectors should assess mechanical wear, hydraulic system condition, and operational smoothness. Common strengths include longevity when properly maintained, efficient load handling, and adaptability to various food processing workflows. Equipment reputation generally remains strong provided previous maintenance records are documented and critical seals show minimal degradation.
